For support in English, ask for help at Nintendo Homebrew on Discord.
  1. 3ds Microsd Management Mac
  2. 3ds Microsd Management Can T Connect
  3. 3ds Micro Sd Manager
  4. 3ds Microsd Management Windows Cannot Access

I scan ports, microsd management use port 139 (netbios). Give a permanent private adress to your 3ds (ex: 192.168.0.2) Try this adress on your browser windows: smb://192.168.0.2. I am running Windows 7 Ultimate x64, my 3DS is a New 3DS XL running the latest firmware and using a stock micro SD card, and my router is a Netgear WNDRMAC running the latest firmware. I tried reseting everything involved and disabling all firewalls, but that did nothing.

If you appreciate this guide, we accept Donations.

Required Reading

The file boot.firm is what is launched by boot9strap itself after it finishes loading off of NAND, and can be any valid arm9 payload in the FIRM format. This file can be replaced at any time, although Luma3DS allows for the launch of other arm9 payloads in the FIRM format using the Luma3DS chainloader.

In this case, we use Luma3DS by AuroraWright to boot a patched SysNAND directly, allowing us to completely bypass the need for any kind of EmuNAND, vastly simplifying the usage of a hacked 3DS in addition to saving SD card space.

During this process, we also setup programs such as the following:

3ds Microsd Management Mac

  • FBI(installs CIA formatted games and applications)
  • Anemone3DS(installs custom themes)
  • Checkpoint(backs up and restores save files for 3DS and DS games)
  • Luma3DS Updater(updates your CFW installation easily)
  • GodMode9(multipurpose tool which can do NAND and cartridge functions)
  • Homebrew Launcher Loader(launches the Homebrew Launcher)
  • DSP1(allows homebrew applications to have sound)
  • ctr-no-timeoffset(removes the rtc offset so that the home menu and rtc timestamps match)

What You Need

  • The latest release of Anemone3DS(the .cia file)
  • The latest release of Checkpoint(the .cia file)
  • The latest release of Homebrew Launcher Wrapper
  • The v1.9.2pre1 release of GodMode9
  • The latest release of DSP1
  • The latest release of FBI(the .cia and .3dsx files)
  • The latest release of ctr-no-timeoffset
  • The latest release of Luma3DS Updater(the .cia file)

Instructions

Section I - Prep Work

  1. Power off your device
  2. Insert your SD card into your computer
  3. Create a folder named 3ds on the root of your SD card if it does not already exist
  4. Create a folder named cias on the root of your SD card if it does not already exist
  5. Copy ctr-no-timeoffset.3dsx to the /3ds/ folder on your SD card
  6. Copy FBI.3dsx to the /3ds/ folder on your SD card
  7. Copy Homebrew_Launcher.cia to the /cias/ folder on your SD card
  8. Copy lumaupdater.cia to the /cias/ folder on your SD card
  9. Copy FBI.cia to the /cias/ folder on your SD card
  10. Copy DSP1.cia to the /cias/ folder on your SD card
  11. Copy Anemone3DS.cia to the /cias/ folder on your SD card
  12. Copy Checkpoint.cia to the /cias/ folder on your SD card
  13. Create a folder named payloads in the luma folder on your SD card if it does not already exist
  14. Copy GodMode9.firm from the GodMode9 .zip to the /luma/payloads/ folder on your SD card
  15. Copy the gm9 folder from the GodMode9 .zip to the root of your SD card
  16. Reinsert your SD card into your device
  17. Power on your device

Section II - Updating the System

If, while following a previous version of this guide, you CTRTransfered your New 3DS to 2.1.0, you should now restore your NAND backup before doing this section.

If, before following this guide, you already had an EmuNAND setup and would like to move the contents of your previous EmuNAND to your new SysNAND CFW, now is the time to follow Move EmuNAND before doing this section.

  1. Update your device by going to System Settings, then “Other Settings”, then going all the way to the right and using “System Update”
    • Updates while using B9S + Luma (what you have) are safe
    • The updater may display a message saying “Your system is up to date” instead of updating. This is normal if you are already up to date; continue with the next section
    • If this gives you an error, set your DNS settings to “auto”
    • If this still gives you an error, follow CTRTransfer, then try updating again

Section III - Homebrew Launcher

  1. Launch the Download Play application ()
  2. Wait until you see the two buttons
  3. Press (Left Shoulder) + (D-Pad Down) + (Select) at the same time to open the Rosalina menu
  4. Select “Miscellaneous options”
  5. Select “Switch the hb. title to the current app.”
  6. Press (B) to continue
  7. Press (B) to return to the Rosalina main menu
  8. Press (B) to exit the Rosalina menu
  9. Press (Home), then close Download Play
  10. Launch the Download Play application
  11. Your device should load the Homebrew Launcher
  12. Launch ctr-no-timeoffset from the list of homebrew
  13. Press (A) to set the offset to 0
    • This will set the system clock to match the RTC date&time (which we will set soon)
  14. Press (Start) to return to the Homebrew Launcher
  15. Launch FBI from the list of homebrew

Section IV - Installing CIAs

  1. Navigate to SD -> cias
  2. Select “<current directory>”
  3. Select the “Install and delete all CIAs” option, then press (A) to confirm
  4. Press (Home), then close Download Play

Section V - DSP Dump

  1. Launch the DSP1 application
  2. Once it has completed, press (B) to self-delete the app and return to the home menu

Section VI - CTRNAND Luma3DS

  1. Power off your device
  2. Launch GodMode9 by holding (Start) during boot
  3. If you are prompted to create an essential files backup, press (A) to do so, then press (A) to continue once it has completed
  4. If you are prompted to fix the RTC date&time, press (A) to do so, then set the date and time, then press (A) to continue
  5. Press (Home) to bring up the action menu
  6. Select “Scripts…”
  7. Select “GM9Megascript”
  8. Select “Scripts from Plailect’s Guide”
  9. Select “Setup Luma3DS to CTRNAND”
  10. When prompted, press (A) to proceed
  11. Press (A) to unlock SysNAND (lvl1) writing, then input the key combo given
  12. Press (A) to continue

Section VII - Cleanup SD Card

  1. Select “Cleanup SD Card”
  2. When prompted, press (A) to proceed
  3. Press (A) to continue
  4. Press (B) to return to the main menu

Section VIII - Backup Essential Files

3ds Microsd Management Can T Connect

  1. Select “Backup Options”
  2. Select “SysNAND Backup”
  3. Press (A) to confirm
    • This process will take some time
    • If you get an error, make sure that you have at least 1.3GB of free space on your SD card
  4. Press (A) to continue
  5. Press (B) to return to the main menu
  6. Select “Exit”
  7. Press (A) to relock write permissions if prompted
  8. Navigate to [M:] MEMORY VIRTUAL
  9. Press (A) on boot9.bin to select it
  10. Select “Copy to 0:/gm9/out”
  11. Press (A) to continue
  12. Press (Home) to bring up the action menu
  13. Select “Poweroff system” to power off your device
  14. Insert your SD card into your computer
  15. Copy <date>_<serialnumber>_sysnand_###.bin, <date>_<serialnumber>_sysnand_###.bin.sha, essential.exefs, and boot9.bin from the /gm9/out/ folder on your SD card to a safe location on your computer
    • Make backups in multiple locations (such as online file storage)
    • These backups will save you from a brick and/or help you recover files from the NAND image if anything goes wrong in the future
  16. Delete <date>_<serialnumber>_sysnand_###.bin and <date>_<serialnumber>_sysnand_###.bin.sha from the /gm9/out/ folder on your SD card after copying it
  17. Reinsert your SD card into your device
  18. Power on your device

Information and Notes

You can now use Luma3DS Updater to update your Luma3DS to the latest version just by opening it and pressing (A).

This is not the same thing as a System Update; it just downloads and extracts the newest Luma3DS files.

This will update the Luma3DS files on your SD card and in CTRNAND, which is what your device boots from when there is no SD card present.

You will now boot Luma3DS CFW SysNAND by default.

You can now hold (Select) on boot to launch the Luma3DS configuration menu.

You can now hold (Start) on boot to launch the Luma3DS chainloader menu (note that the Luma3DS chainloader menu is only displayed if there is more than one payload detected).

You can now hold (Start) + (Select) + (X) on boot to dump the ARM11 bootrom (boot11.bin), the ARM9 bootrom (boot9.bin), and your console unique OTP (OTP.bin) to the /boot9strap/ folder on your SD card (note that this will not have any kind of prompt or message).

You can now press (L) + (Down) + (Select) while the system is booted to open the Rosalina menu integrated into Luma3DS. For a full list of Rosalina features, please see the Luma3DS v8.0 Release

If you would like to upgrade to a bigger sized SD card, all you have to do is format your new SD card as FAT32 and copy paste the contents of the old SD card onto the new SD card.

If your new SD card is bigger than 32GB, then you have to use a different tool to format it, such as guiformat (Windows), Disk Utility (Mac), or cfdisk (Linux).

For information on changing your device to another region, check out the Region Changing page.

For information on using GodMode9’s various features, check out the GodMode9 Usage page.

3ds Micro Sd Manager

For information on using Luma3DS’s various features, check out its wiki.

For information on installing custom themes and splash screens, check out Theme Plaza.

For information on using Gateshark cheat codes on Luma3DS, check out Checkpoint.

Summary :

Format 3DS SD card to FAT32 is necessary if you need to use it on 3DS console. The format tool we mentioned in this post also applies to SD cards for New Nintendo 3DS, New Nintendo 3DS XL, New Nintendo 2DS XL, Nintendo 3DS XL, and Nintendo 2DS.

Quick Navigation :

About 3DS SD Card

3ds What Is 3DS SD Card? As the name implies, 3DS SD card is a kind of SD card that can be used on 3DS. Then what is 3DS? Released by Nintendo, 3DS is a handheld gaming device that enables you to play your favorite games anyplace at anytime. Its featured face-tracking 3D, fast processing speeds, amiibo support, and built-in entertainment options make it the best way to play.

What SD Cards Are Compatible?

3ds Microsd Management

Then what kind of SD card is compatible with Nintendo 3DS? Here we list some SD cards that have been proved to be compatible with Nintendo 3DS by Nintendo Support. You can purchase any of them to be used as 3DS SD card.

3ds

SanDisk Extreme:

3ds Microsd Management Windows Cannot Access

  • 16 GB [SDSDQXN-016G-G46A]
  • 32 GB [SDSDQXN-032G-G46A]

SanDisk Extreme PLUS:

  • 16 GB [SDSDQX-016G-U46A]
  • 32 GB [SDSDQX-032G-U46A]

SanDisk Extreme Pro:

  • 16 GB [SDSDQXP-016G-X46]
  • 32 GB [SDSDQXP-032G-G46A]

Toshiba:

  • 8 GB [SD-C008UHS1(BL5A)]

But does this mean only the SD cards listed above can be used as 3DS SD card? Absolutely not! Nintendo Support also explains the SD card requirements for users to select SD card by themselves.

Note: Information applies to New Nintendo 3DS, New Nintendo 3DS XL, New Nintendo 2DS XL, Nintendo 3DS, Nintendo 3DS XL, and Nintendo 2DS. Products other than the included SD cards are not guaranteed to work.
  • The Nintendo 3DS, Nintendo 3DS XL, and Nintendo 2DS systems are compatible with SD cards up to 2 GB in size, and SDHC cards of 4 GB and larger up to 32 GB in size. All other SD card types are not considered compatible. MiniSD and MicroSD cards are compatible with the use of an SD card adapter.
  • The New Nintendo 3DS family systems are compatible with MicroSD cards up to 2 GB in size, and MicroSDHC cards of 4 GB and larger up to 32 GB in size. All other SD Card types are not considered compatible.
  • SDXC and MicroSDXC cards are not considered compatible.

What Exactly Is the 3DS SD Card Format?

Although Nintendo 3DS comes with a standard 2GB or 4GB SD card for storage, you may intend to upgrade your 3DS standard SD card to another SD card with larger storage capacity. Then it is important for you to know the exact file system requirement for the new SD card.

So far the Nintendo 3DS, Nintendo 3DS XL, Nintendo 2DS and the New Nintendo 3DS family systems all accept SD card formatted to FAT32 file system. That is to say, if you want to put in a 32GB SD card that has an NTFS or Ext2/3/4 file system to 3DS, you will have to reformat it to FAT32.

How Do You Know whether You Need to Format SD Card for 3DS?

As Nintendo console needs a FAT32 format for SD and SDHC cards, you must be very clear about what file system your memory card comes with and whether it needs to be formatted. To check whether your SD card has a FAT32 file system, you can connect it to computer, open File Explorer, and view its properties.

So the bottom line here is, 3DS SD card should be SD/SDHC card with a capacity equal or less than 32GB and should be formatted to the FAT32 file system. If your SD card has a different file system, reformat it to FAT32.

How to Reformat 3DS SD Card with FAT32 File System

3ds microsd management does not work

In this part, we list 4 solutions here for you to format 3DS SD card to the FAT32 file system, with detailed instructions and corresponding pictures. But no matter which way you choose, you need to do the preparatory job first.

Preparatory work:

  • Make sure you have a computer running Windows 10/8/7.
  • Make sure the 3DS SD card you intend to format is successfully connected and recognized by the Windows PC.
  • Make sure the SD card is ready to be formatted because formatting will lead to data loss. If you have some important files in it, make a backup in advance. And the guide Clone SD Card to PC for Transferring Data or Making a Backup may be helpful to you.

Solution 1. Format 3DS SD Card in MiniTool Partition Wizard

In our experience, disk partition manager is always the first choice when we come across various disk partition issues because such kind of tool is easier to use. MiniTool Partition Wizard Free Edition - an excellent choice for disk partition maintenance - is strongly recommended here. This free partition manager is able to address a lot of issues such as 'low disk space warning', 'file is too large for the destination file system', '3TB hard drives only uses 2TB', etc. To reformat 3DS SD card to FAT32 file system, MiniTool Partition Wizard offers powerful Format Partition feature. Click the button to get this free yet professional partition manager first and then install it on computer.

We will see how this SD card formatter works on 3DS SD card formatting.

Step 1. Run MiniTool Partition Wizard and enter the main interface. Then select the 3DS SD card partition from the disk map and choose Format Partition from the action panel.

Step 2. In the pop-up window, you can drop down the File System box and choose FAT32 as the destination file system. Then click OK to go back to the main interface of MiniTool Partition Wizard.

Step 3. You can preview the SD partition will have a FAT32 file system. Now you need to click Apply button from the top left corner to save all changes.

Tip 1: Usually, only one partition is created on the SD card. If you have got more partitions on the SD card, you should use MiniTool Partition Wizard to delete all partitions first, and then create a FAT32 partition on the unallocated space.

Management

Tip 2: Also some users report that SD card beyond 32GB is also accepted by Nintendo 3DS as long as the card is formatted to FAT32... If you want to have a try, you can use MiniTool Partition Wizard to help you, because Windows built-in tools refuse to format memory card larger than 32 GB to FAT32 file system but MiniTool Partition Wizard enables.

We also recommend reading our guide: SD Card Formatter | How Do I Format SD Card Quickly.

Solution 2. Format 3DS SD card in Command Prompt

We have also recommended this Windows built-in tool so many times when we have the requirement to manage hard drive partitions. This SD card formatter requires your familiarity with your drives as no preview or warning message is presented before the execution. However, the commands involved here are easy, and you only need to run the followings to format SD card for 3DS.

3ds Microsd Management

Step 1. At Windows Start menu, run Command Prompt as administrator.

Step 2. Type the following commands and end each one with Enter key:

  1. Diskpart
  2. List disk
  3. Select disk n (n is the disk number of the SD card)
  4. List partition
  5. Format fs=fat32 quick
  6. Exit (exit diskpart)
  7. Exit (exit Command Prompt)

Solution 3. Format 3DS SD card in Disk Management

How do you think of Windows Disk Management? Yes easy to access, and also easy to use even for average users. Indeed, Disk Management is another SD formatter that can be used to format 3DS SD card to FAT32 file system. Please do as the follows:

Step 1. Run 'diskmgmt.msc' to launch Windows Disk Management utility. Then you will see all your hard drives and removable disks attached to your computer are shown there. Please find the 3DS SD card partition by viewing the partition size and drive letter, then right-click it and choose Format from the context menu.

Step 2.In the pop-up window, choose FAT32 as the destination file system and click OK.

Step 3. You will see a warning message that reads 'Formatting this volume will erase all data on it. Back up any data you want to keep before formatting. Do you want to continue?' Please click OK to start the formatting if you have finished the preparatory work well. Disk Management will finish the formatting within a minute.

Solution 4. Format 3DS SD card in File Explorer

You must be familiar with File Explorer, the place to access your drives and files, we believe. How does it help to format 3DS SD card? Well, open File Explorer and find the SD card partition by viewing the drive letter and partition size. Then, follow the steps below to format SD card for 3DS.

Step 1. Right-click the SD card partition and choose Format from the context menu.

Step 2. In the pop-up window, drop down the file system list and choose FAT32 as the desired file system. Then click Start button.

Step 3. A warning message saying formatting will erase all data on this disk appears. Again if your SD card is ready for the formatting, click OK start and wait for the success.

We also recommend reading our guide: How Do I Fix 'Windows Was Unable to Complete the Format' Error.

How to Perform SD Card Recovery after Wrong Formatting

While the theme of this post is to reformat SD card for 3DS, sometimes you may forget to transfer/back up the important files from the SD card before formatting it to FAT32. In this case, we still have a nice suggestion for you to do SD card data recovery.

MiniTool Partition Wizard Free Edition, which is free to recover 1GB data, is recommended here. Although 1GB seems insufficient for your data recovery, you can use this freeware to scan your 3DS SD card and see whether it works before you pay a penny. With powerful Removable Disk Drive module, it should have no problem in scanning the SD card and finding the desired files for you. Get this SD recovery software now by hitting the download button and install it on your computer.

Detailed instructions are as follows:

Step 1. Launch MiniTool Partition Wizard and choose Data Recovery.

Step 2. Select the 3DS SD card partition in Removable Disk Drive module to have a full scan and wait patiently until the scanning process is finished.

Step 3. After a while, Data Recovery has finished scanning every sector of the SD card and lists the partitions it finds for you. (At most 10 partitions are listed each time if too many partitions were created in history. You can click Back button at lower right corner to load other partitions if there is a need.) Please unfold each folder and check the needed files manually. Finally, click Save to choose a safe location (should be a different route from the SD card partition to avoid overwriting) to store the files you have just selected.

Tip: If you have got more than 1GB files to recover, you may purchase a pro ultimate to break the limitation.

Summary

Reading here, we believe you know what is 3DS SD card, what SD card is compatible with 3DS, what is 3DS SD card format, how to reformat SD card for 3DS, and how to carry out SD card data recovery if wrong formatting happens. If you have any questions or suggestions toward how to format SD card using MiniTool software, you can leave them in the comment section below or contact us via [email protected]. Thanks in advance!
